Product Management — OraScan AI Platform
94.7% accuracy across 11 oral disease categories — the product definition behind the AI.
Accuracy Target Set & Met
Training Images Curated
Disease Classes Defined
Tools & Methods
The Problem
Most people in smaller Indian cities skip regular dental checkups because specialists aren't nearby and consultations cost too much. The goal was to make AI-powered oral screening available on a simple kiosk — so any clinic, even without a specialist on staff, could flag problems before they became serious.
The Challenge
Oral diseases affect over 3.5 billion people globally but go undiagnosed in low-resource settings due to the cost of specialist consultations. The PM challenge was defining a product that was both clinically credible and deployable on GPU-less kiosk hardware at dental clinics. This meant setting meaningful per-class accuracy targets — not just a single aggregate metric — across 11 disease categories with severe class imbalance (common: caries, calculus; rare: mucocele, hypodontia) and specifying dataset curation criteria that would drive a reproducible, bias-reduced training corpus. The go-to-market path had to be defined upfront: kiosk-first deployment with a REST API layer for future integrations, rather than cloud-first with a latency penalty.
Product Requirements Document
PRODUCT REQUIREMENTS DOCUMENT
OraScan — AI Oral Disease Detection
Varun Cumbanungam · AI Product Manager · Oralens HealthCare (2023)
Doc ID
ORS-PRD-V1
Status
Approved
Owner
Varun C.
Date
2023
Version
1.0
Problem Statement
Oral diseases affect 3.5B people globally but go undiagnosed. The product must classify 11 disease classes at ≥94% accuracy on GPU-less kiosk hardware in under 200ms.
Disease Classes & Dataset
- Caries, Calculus, Gingivitis — high-prevalence classes
- Periodontal disease, Oral cancer — critical recall required
- Hypodontia, Mucocele, Ulcer, Fluorosis + more
- 78,058 labelled images (DENTEX + SMART-OM datasets)
- Class imbalance: weighted sampling + CutMix augmentation
Model & Deployment Strategy
- EfficientNet-B0 backbone — 4.67M parameters
- PyTorch + AMD GPU (DirectML) training pipeline
- ONNX INT8 export — edge kiosk CPU deployment
- 23 training iterations tracked in Edge Impulse
Key Acceptance Criteria
- AC-1Overall test accuracy ≥94% across all 11 classes
- AC-2Oral cancer recall ≥97% — no false negatives
- AC-3ONNX INT8 inference on CPU under 200ms
- AC-4Model size under 20MB post-quantisation
- AC-5FastAPI inference server p95 under 300ms
- AC-6Accuracy drop post-INT8 quantisation under 1%
Key Risks
- HIGH
Oral cancer false negative — missed diagnosis
Recall ≥97% gate + clinical review threshold
- HIGH
INT8 accuracy regression on kiosk hardware
Per-class evaluation before deployment sign-off
- MED
Dataset class imbalance skews model
Weighted sampling + confusion matrix gate
Product Artefacts Delivered
- PRD V1 — disease scope, dataset strategy, ACs
- Model evaluation — per-class metrics, confusion matrix
- ONNX deployment spec — INT8 quantisation runbook
- Kiosk integration guide — FastAPI + hardware setup
CONFIDENTIAL · OraScan PRD · Property of Oralens HealthCare
PRD · Model Evaluation · ONNX Deployment Spec · Kiosk Guide
Full PRD and supporting artefacts available upon request
Results
The model shipped meeting the 94.7% test accuracy target across all 11 disease classes. ONNX INT8 quantisation met the <200 ms kiosk inference latency requirement without meaningful accuracy regression. The product was integrated into two workflows — automated scanning (MediaPipe FaceMesh-triggered) and manual desktop scanning — enabling OraScan to serve both high-throughput kiosk and assisted-diagnosis use cases from a single model artefact.
Gallery & Demos
AI Analysis Results Screen
Kiosk interface displaying disease classification output across all 11 oral condition categories with confidence scores.
Web Portal — Clinical Dashboard
Clinician view showing patient scans, historical analysis, and disease progression tracking.
Click any image or video to expand · ← → keys navigate
